NEW P1

Book your demo @ wintersaudio

LUMIN P1 makes system integration easier than ever:

• 9 digital & analogue inputs

• USB digital audio input & output support up to Native DSD512

• Balanced & unbalanced analogue inputs

• SPDIF & AES input support up to 192/24 & DoP

• HDMI 2.0 inputs & 4K passthrough with ARC support

Specified for exceptional musical performance:

• New processor delivers native DSD512 & PCM384 playback

• Dual Mono design throughout maximises channel separation

• Dual ES9028PRO SABRE DACs in Mono mode

• Femto Clock System with precision FPGA distribution

• New integrated dual-toroidal linear power supply & all-in-one chassis

• Fibre Network provides complete isolation from network digital noise

• Leedh Processing lossless volume control

• DSD Support:

  • Up to DSD512 22.6MHz, 1-bit

• PCM Support:

  • Up to 768kHz, 16–32-bit, Stereo

• Analog Output Stage:

  • Dual ESS SABRE32 ES9038Pro DAC chips

  • Fully balanced layout with high-quality components

  • Output connectors coupled with dual LUNDAHL LL7401 output transformers

  • Femto Clock System with precision FPGA distribution

• Upsampling rates & bit depths:

  • DSD128 upsampling option for all files

  • PCM 384kHz upsampling option for all files

  • Digital Output Stage:

  • USB:

  • Native DSD512 support

  • PCM 44.1–768kHz, 16–32-bit, Stereo

  • BNC SPDIF:

  • PCM 44.1kHz–192kHz, 16–24-bit

  • DSD (DoP, DSD over PCM) 2.8MHz, 1-bit

  • Optical Network

• Industry-standard SFP

• 1000Base-T Gigabit Ethernet

• Adapter may be needed for your particular switch/cables

• Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)

• Power Supply:

• External solid billet cnc dual-toroidal

• Separate digital & analogue circuitry

• Low-noise linear regulator

• 9-pin Output Connector

• Physical:

• Finish:

• Black anodised brushed aluminium (with matching PSU)

• Raw brushed aluminium (with matching PSU)

• Lumin (solid aluminium chassis):

• 350mm (W), 345mm (D), 60mm (H), 8kg

• PSU (solid aluminium chassis):

• 106mm (W), 334mm (D), 60mm (H), 4kg

• Supported Audio File Formats:

• DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)

• PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF

• Compressed (lossy) Audio: MP3, AAC (in M4A container)

• MQA

​

• New generation processor provides DSD512 and 384kHz playback

• Dual ES9028PRO SABRE DACS

• USB digital audio output

• Precision 32-bit internal digital volume

• Discreet clock system for precision timing

• Low-noise switching power supply with dual stage regulator

• Resampling to every supported format up to DSD128 and PCM384kHz

• MQA full decoding

• Roon Ready, Spotify Connect, MQA, TIDAL, Qobuz, TuneIn and AirPlay-compatible

• New CNC panelled construction offers upgraded structural rigidity and sheilding compared to the T1

• The newly-designed thick cnc panels provide the high-end LUMIN family aesthetic

• From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want

• Native support for TIDAL, Qobuz, Spotify and AirPlay-compatible, giving you access to tens of millions of songs

• The unique and intuitive LUMIN App described as "the most convenient interface in existence" by TINMAN

• LUMIN programme of continuous development that has seen Roon, MQA, and Spotify support added in 2017 alone.

• We put a huge amount of effort into sourcing the highest-grade matching components, creating truly balanced circuits, designing cases that shield from interference, etc, etc, but it's only important if the end result effectively communicates the intentions of the artist.

• Notably, the common thread in every published and consumer review of all LUMIN products is musicality.

• DSD Support:

  • Up to DSD128 5.6MHz, 1-bit

• PCM Support:

  • Up to 384kHz, 16–32bit, Stereo

• Upsampling rates & bit depths:

  • DSD upsampling option for all files up to 96kHz

  • PCM 192kHz upsampling option for all files up to 96kHz

• Analog Output Stage:

  • Wolfson WM8741 DAC chips, 1 chip per channel

  • Fully balanced layout with high-quality components

• Digital Output Stage:

  • BNC SPDIF:

    • PCM 44.1kHz–192kHz, 16–24-bit

    • DSD (DoP, DSD over PCM) 2.8MHz, 1-bit

    • Power Supply:

    • Internal 100–240V AC auto-ranging

    • Physical:

    • Finish:

    • Raw brushed aluminium or black anodised brushed aluminium

    • D2 unit:

    • 300mm (W), 244mm (D), 60mm (H), 2.5kg

    • Packaging:

    • 470mm (W), 340mm (D), 170mm (H), 4.5kg

• App Features:

• Native support for TIDAL, MQA, Qobuz and TuneIn Radio.

• Tidal MQA icons to identify high-res music

• Qobuz high-res icons to identify high-res music

• Volume control

• High-resolution artwork

• Artwork caching

• Search

• Multiple tag handling

• Composer tag support

• Album-grouping in playlist

• Automatic internet links to artists/album/songs

• Saving and restoring of playlists (including Tidal and Qobuz)

• Supported Audio File Formats:

• DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)

• PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF

• Compressed (lossy) Audio: MP3, AAC (in M4A container)

• MQA

• Leedh Processing lossless digital volume control

• Programme of Continuous Development – Firmware-upgradable for further features and enhancements
